| Parameter |
SPECIFICATION |
| Universal Inputs |
Minimum 12 universal inputs supporting HDMI 1.3/1.4/2.0, DVI-I, SDI,
HDBaseT, IP (RJ45 decoding) with capability up to 56 HD or 28 4K input
channels. System shall support decoding up to 16 channels of
4K@30Hz via IP input cards and must be capable of displaying minimum
8 concurrent live sources simultaneously. |
| Video Outputs |
Minimum 8 digital outputs, expandable up to 20 HD/4K outputs per
chassis. Output interfaces shall include HDMI (up to 2.0 – 4K@60Hz),
DVI-I, SDI, HDBaseT (Cat5/6 up to 70m). Each output shall support
3840×2160 @ 60Hz, backward compatible with FHD (1920×1080) /
WUXGA (1920×1200). |
| Video Processing |
Advanced multi-window and multi-source display capability with
independent window resizing, positioning, cropping, layering, and
flexible wall geometry management. Support for custom resolutions,
warp & blend for projector-based walls, and RGB 4:4:4 color processing. |
| Video Decoding |
Supports HD (1920×1200@60Hz), Full HD (1920×1080@60Hz), and 4K UHD (3840×2160@60Hz). IP decoding capability up to 4K@30Hz per channel. Scalable multi-view configurations (2x2, 3x3, 4x4 layouts). |
| Latency |
Ultra-low latency processing with ≤ 20 ms source switching, ≤ 16 ms window creation, ensuring overall input-to-wall latency ≤ 50 ms. |
| Processor (CPU) |
9216Bytes |
| Graphics (GPU) |
Dedicated professional graphics processing (for PC architecture) such as NVIDIA RTX / Quadro / A-Series with minimum 8 GB VRAM for real-time rendering and visualization. |
| RAM |
Minimum 32 GB DDR4/DDR5 RAM, expandable up to 64 GB or higher (for PC-based configuration). |
| Storage |
Minimum 1 TB SSD (NVMe preferred) for OS, application software, and system logs (where applicable). |
| Operating System |
Either: 1) Embedded OS-less appliance architecture (virus-free, no update dependency) OR 2) 64-bit Windows 10/11 IoT Enterprise / Linux-based OEM OS optimized for control room operations. |
| Mounting |
Industrial-grade 6RU rack-mount chassis, suitable for standard 19-inch racks. |
| Control & Management |
Centralized control platform with Open API (TCP/IP & RS232). Features include layout customization, preset recall, remote configuration, remote ON/OFF capability, EDID management, HDCP 1.4 & 2.2 compliance, and third-party integration capability. |
| Power Supply |
Redundant (1+1) hot-swappable power supplies ensuring high availability and uninterrupted operation. |
| Environmental Compliance |
Contact 6KV, Air 8KVOperating temperature: 0°C to 50°C; Humidity: <90% non-condensing. |
| Accessories |
Industrial keyboard and optical mouse (for PC-based configuration), along with necessary control interfaces. |
| Cables & Connectivity |
All necessary HDMI / DVI / SDI / HDBaseT / LAN cables and connectors required for integration with display panels shall be supplied. |
| Display Compatibility |
Compatible with LCD, LED, Video Cubes, Projectors, and custom display resolutions. |
| Compliance |
ISO / RoHS / CE / FCC standards compliant. |
